See crystal-clear, vibrant images from a distance in lecture halls, auditoriums or any large venues with up to 5,000 lumens of brightness.
Acer ColorBoost3D™
Reproduce lifelike colors and brilliantly bright images with Acer ColorBoost3D™ technology.
WXGA Resolution
With 1280×800 WXGA resolution, project in confidence with sharper, more detailed images and video than you have come to expect from standard projectors.
Acer LumiSense™
Acer LumiSense™ adjusts the image brightness and color saturation based on the content you're viewing.
Acer BlueLightShield™
Protect your eyes from unnecessary strain by utilizing Acer BlueLightShield™ technology.
Acer ColorSafe II
Enjoy consistent, natural colors with ColorSafe II technology, which controls the dynamic RGB levels to prevent color decay.
Automatic Vertical Keystone Correction
Finding the right angle for your presentation is easier with auto keystone correction, which corrects vertical distortion.
Integrated Speakers[1]
What you hear will be just as good as what you see with the powerful built-in speakers.
Eco-Mode
Enjoy power-saving features that extend lamp life, auto-shut down when idle, and reduce noise levels when in Eco mode.
Tech Specs
Native Resolution
1280 x 800
Maximum Resolution
1920 x 1200
Standard Mode Brightness
5000 lm
Low Mode Brightness
4000 lm
Compatible Aspect Ratio
4:3
16:9
Native Aspect Ratio
16:10
Contrast Ratio
20,000:1
Throw Ratio
1.54 to 1.72 (1524 mm@2000 mm)
Digital Zoom
2x
Zoom Ratio
1.1:1
Vertical Keystone Correction
-40°/+40°
Maximum Vertical Sync
120 Hz
Minimum Vertical Sync
24 Hz
Maximum Horizontal Sync
100 kHz
Minimum Horizontal Sync
15 kHz
Colour Supported
1.07 Billion Colors
Uniformity
80%
Graphic Mode
WUXGA
Standard Mode Brightness Disclaimer
Compliant with ISO 21118 standard
Projection Lens
Lens Type
Manual Focus
Manual Zoom
Minimum Lens Aperture
f/2.41
Maximum Lens Aperture
f/2.53
Minimum Focal Length
21.85 mm
Maximum Focal Length
24 mm
Minimum Diagonal Image Size
685.80 mm
Maximum Diagonal Image Size
7.62 m (300")
Minimum Projection Distance
1 m
Maximum Projection Distance
10 m
Optical Zoom
1.1x
Lamp
Lamp Type
OSRAM
Number of Lamps
1
Lamp Power
240 W
Normal Mode Lamp Life
5000 Hour
Economy Mode Lamp Life
10000 Hour
ExtremeEco Mode Lamp Life
15000 Hour
Interfaces/Ports
HDMI
Yes
HDMI Version
HDMI 1.4b
Number of USB Ports
2
USB
Yes
USB Connector Type
2 x Type-A
Number of Composite Video Ports
1
Composite Video
Yes
Number of Component Video Ports
1
Component Video
Yes
Number of VGA Outputs
1
VGA Out
Yes
Number Of Audio Inputs
1
Number Of Audio Outputs
1
Audio Line In
Yes
Audio Line Out
Yes
Total Number of HDMI Ports
2
HDMI Detail
HDMI1.4b (HDCP 1.4) x 2
USB Detail
DC Out (5V/1A, USB Type A) x 1,USB (Type A) x 1, share output port
RS-232 (D-sub)
1
HDMI
HDMI1.4b (HDCP 1.4) x 2
VGA Out
x1, D-sub
Component
x1 RCA
Video
x1, RCA
Audio In
x1, 3.5mm mini jack
Audio Out
x1, 3.5mm mini jack
S/PDIF
Speaker
x1.0, 3 W Speaker
x1.0, 3 W Speaker
Technical Information
Projection System
DLP
Projection Method
Front Ceiling
Rear
Front
Rear Ceiling
Video Compatibility
NTSC
SDTV
PAL
SECAM
EDTV
HDTV
Computer Compatibility
Mac PC
Google Chrome PC
Windows PC
Horizontal Scan Range
15 kHz – 100 kHz
Vertical Scan Range
24 Hz – 120 Hz
Offset
125%
Noise Level (Economy Mode)
27 dB
Audio
Number of Speakers
1.0
Speaker Output Power
3 W
Display/Image
Projection System
DLP™
Light Source
240 W OSRAM
Light Source Life
5000 hours (Standard), 10000 hours (ECO)
Native Resolution
1280 x 800
Maximum Resolution
1920 x 1200
Brightness
5000 ANSI Lumens (Standard), 4000 lm (ECO), (Compliant with ISO 21118 standard)
Aspect Ratio
16:10 (Native), 4:3 (Supported), 16:9 (Supported)
Contrast Ratio
20,000:1
Image Size
27" (68.6 cm) ~ 7.62 m (300")
Keystone Correction
+/- 40° (Vertical, Manual & Auto)
Throw Ratio
1.54 to 1.72 (1524 mm@2000 mm)
Zoom Ratio
1.1x
Digital Zoom
2x
Lens
F = f/2.41~f/2.53, f = 21.85 mm~24 mm, Manual Focus, Manual Zoom
Projection Mode
Front Ceiling, Rear, Front, Rear Ceiling
Display Colour
1.07 billion
1.07 billion
Vertical Sync Rate
24 ~ 120 Hz
Horizontal Sync Rate
15 to 100 kHz
Control & Network
RS232
x1, D-sub
General
Noise Level
27 dB
Security
Kensington Lock
Security Bar
Power Description
Power Supply
100 V AC ~ 240 V AC
Input Voltage
120 V AC
230 V AC
Operating Power Consumption
275 W
Standby Power Consumption
500 mW
Physical Characteristics
Fan Noise
27 dB(A) Approximate Economy Mode
Operating Temperature
0°C to 40°C
Operating Humidity
80%
Installation
Ceiling Mount
Security
Kensington Lock
Security Bar
Weight (Approximate)
2.80 kg
Form Factor
Ceiling Mountable
Height
113.7 mm
Width
313 mm
Depth
240 mm
Miscellaneous
Optional Accessories
Carrying Case (MC.JPV11.005)
Lamp (MC.JTG11.003)
Standard Accessories
AC Power Cord
Battery for remote control
Lens Cap
Quick Start Guide
Remote Control
Security Card
VGA Cable
Weight
3.00 kg
Dimensions
35.00 × 25.00 × 20.00 cm
