DL30
Distance Learning Tracking Camera

Boost Your Distance Learning with Auto Tracking

Distance Learning Tracking Camera

When distance learning and hybrid classrooms are the new normal, the AVer DL30 is a must-have solution for online education. With the DL30 connected to a laptop, you can present freely onstage while livestreaming so students can learn no matter where they are. Teachers don’t need to be camera shy anymore—they can just be themselves and teach how they want thanks to the DL30 tracking camera!



Perfect for Online & Offline Education

Simple controls and plug-and-play connectivity are the biggest advantages of the DL30, which is ideal for installing in every classroom. Students tuned in remotely and those present in the classroom can see each other and learn together like they would if they were in the same room. Enhance student engagement and interaction, and easily create distance learning and hybrid learning environments.

12X Optical Zoom

The DL30 is equipped with a 12X optical zoom that operates smoothly without distorting the image. It clearly presents the classroom blackboard panorama and medium, close-up, and long-distance shots of the teacher, providing stable shooting capability while maintaining detailed quality. With the DL30 running the show, teachers no longer need to suppress their creativity in hybrid environments

AI-Powered Human Detection

AVer’s renowned Human Detection automatically recognizes human forms in the classroom and dynamically tracks specific targets or areas via multiple tracking modes. The target doesn’t need to wear any devices or sensors to maintain tracking. Even far-site students can clearly follow the teacher’s every move.

Presenter Mode

Superb tracking and anti-interference functions allow teachers to move freely in the classroom. Instructors can adjust the tracking settings, stream, and record to make their teaching more substantive and vivid. To change the tracking target, users can simply click one button on the remote control.

Zone Mode

Accurate segmented tracking clearly shows content on the blackboard or screen, automatically switching the tracking area according to the teacher's position. Content and the presenter are displayed at the same time so students can understand notes for key points at a glance.



Specifications

Camera

Image sensor

• 1/2.8' 1080p Low Lux CMOS

Effective Picture Elements

• 2 Megapixels

Output Resolution

• 1080p/60 (IP Streaming & USB)

Minimum Illumination

• 0.5 Lux (IRE50, F1.6, 30fps)

S/N Ratio

• > 50 dB

Gain

• Auto, Manual

TV Line

• 800 (Center), 600 (Corner)

Shutter Speed

• 1/4 to 1/10,000 sec (60 Hz)
• 1/3 to 1/10,000 sec (50 Hz)

Exposure Control

• Auto, Manual, WDR

WDR

• Yes

White Balance

• Auto, Manual

Optical Zoom

• 12X

Digital Zoom

• 2X

Viewing Angles

• DFOV : 84.1° (Wide) to 7.8° (Tele)
• HFOV : 76.5° (Wide) to 6.8° (Tele)
• VFOV : 47.3° (Wide) to 3.8° (Tele)

Focal length

• f = 3.9 mm (Wide) to 46.8 mm (Tele)

Aperture (Iris)

• F = 1.6 (Wide) to 2.8 (Tele)

Minimum Working Distance

• 0.3 m (Wide), 1.5 m (Tele)

Pan / Tilt Angles

• Pan : ±170°, Tilt : ±90°

Pan / Tilt Speed (Manual)

• Pan: 1° to 90°/sec
• Tilt: 7.85° to 45°/sec

Preset Speed

• Pan : 120° / sec, Tilt : 110.84° / sec

Preset Positions

• 10 (IR), 256 (IP & USB)

Camera Control – Interface

• IP, USB

Camera Control – Protocol

• VISCA (IP), CGI (IP), USB

Image Processing

• Noise Reduction (2D/3D), Flip, Mirror, WDR

Power Frequency

• 50Hz / 60Hz

AI Auto Tracking Functions

Tracking Modes

• Presenter Mode, Zone Mode, Hybrid Mode

Privacy Protection Mechanisms

Protection Modes

• Privacy Mode, Sleep Mode

Audio

Channels

• 2ch (Stereo)

Codecs

• AAC, PCM

Sample Rate

• AAC (48, 32, 16, 8 KHz), PCM (48 KHz)

Interface

Video Outputs

• IP, USB

Audio Outputs

• IP, USB

Audio Inputs

• Mic in, Line in

General

Power Requirement

• AC 110–220V to DC 12V/2A

Power Consumption

• 12W

PoE

• PoE+

Dimensions (W x H x D)

• 158.8 x 200.0 x 162.2 mm

Net Weight

• 1.62 (±0.1) kg

Application

• Indoor

Tally Lamp

• N/A

Security

• Kensington Slot

Remote Control

• Infrared

Operating Condition

• Temperature: 0°C to 40°C
• Humidity: 20% to 80%

Storage Condition

• Temperature: -20°C to 60°C
• Humidity: 20% to 95%

IP Streaming

Resolution

• 1080p 60fps

Network Video Compress Formats

• H.264, MJPEG (Web Page)

Network Audio Compression Formats

• AAC

Sample Rates

• 48, 32, 16, 8 KHz

Maximum Frame Rate

• 1080p 60fps

Bit-rate Control Modes

• VBR, CBR

Range of Bit-rate setting

• 512 Kbps to 32 Mbps

Network Interface

• 10/100 Base-T

Multi-stream Capability

• 2 (1 for IP Streaming, 1 for Web Page), (1 for USB, 1 for Web Page),1080p 60fps (max.)
• 3 (1 for IP Streaming, 1 for Web Page, 1 for USB), 1080p 30fps (max.)

Network Protocol

• IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP

NDI^®|HX Capability

• N/A

USB

Connector

• USB 3.1 Gen 1 Type-B

Video Formats

• MJPEG, YUY2

Maximum Video Resolution

• 1080p

USB Video Class (UVC)

• UVC1.1

USB Audio Class (UAC)

• UAC1.0

Web UI

Live Video Preview

• Yes

Camera PTZ Control

• Pan / Tilt / Zoom / Focus / Preset Control

Camera / Image Adjustment

• Exposure / White Balance / Picture

Network Configuration

• DHCP, IP Address, Gateway, Subnet Mask, DNS

Software Tools

IP Search and Configuration Tool

• Supports Windows^® 7 or later

PTZ Management

• Supports Windows^® 7 or later

PTZ Control Panel

• Supports iOS & iPadOS^® 9 or later

CaptureShare

• Supports Windows^® 7 or later, macOS^® 10.14 or later

PTZ Link

• Supports Windows^® 7 or later, macOS^® 10.14 or later

Warranty

Camera

• 3 Years

Accessories

• 1 Year

Package Contents

• Camera, Remote Control, Power Adapter, Power Cord, USB Cable, Cable Ties (x4), Cable Fixing Plate (x1), M2 x 4mm Screws (x2), 1/4'-20L 7.5mm Screw (x1), Quick Start Guide

Optional Accessories

• Wall Mount Kit (Brackets (x2), M4 x 8mm Screws (x2), 1/4'-20L 7.5mm, Screw (x1), Wall Mount Kit Installation Guide), Ceiling Mount Kit (Brackets (x2), M3 x 6mm Screws (x3), 1/4'-20L 7.5mm, Screws (x3), Ceiling Mount Kit Installation Guide)
