ISO/IEC 19798

2100 pages

ISO/IEC 19798

1900 pages

ISO/IEC 19798

1900 pages

ISO/IEC 19798

1900 pages

ISO/IEC 19798

7600 pages

ISO/IEC 19798

5500 pages

ISO/IEC 19798

5500 pages

ISO/IEC 19798

5500 pages

Printing Method

Colour Laser Beam Printing

Print Speed

A4^*1 (Mono/Colour)

33 / 33 ppm

Letter^*1 (Mono/Colour)

35 / 35 ppm

2-Sided, A4 (Mono/Colour)

29 / 29 ipm

Print Resolution

600 x 600 dpi

Print Quality with Image Refinement Technology

1,200 x 1,200 dpi (equivalent)

Warm-Up Time (From Power On)

14 sec or less

First Print Out Time (FPOT) (Approx.)^*2

A4 (Mono/Colour)

7.1 / 7.1 sec

Print Language

UFR II, PCL 6, Adobe® PostScript® 3™

Auto Duplex Print

Yes

Print Margins

Top/Bottom/Left/Right Margin: 5 mm
Top/Bottom/Left/Right Margin: 10 mm (Envelope)

Supported File Format for USB Direct Print

JPEG, TIFF, PDF

Input Tray Capacity (Plain Paper, 80 g/m²)

Standard

Cassette

250 sheets

Multi-Purpose Tray

50 sheets

Optional

Paper Feeder

550 sheets

Maximum

850 sheets (Cassette + 1 Paper Feeder)

Output Tray Capacity (Plain Paper, 80 g/m²)

150 sheets

Media Size

Cassette

A4, A5, A6, Legal, Letter, Foolscap, Indian Legal, Envelope (COM10, Monarch, DL, C5), Custom (min. 98.0 x 148.0 mm to max. 216.0 x 356.0 mm)

Paper Feeder

A4, A5, A6, Legal, Letter, Foolscap, Indian Legal, Custom (min. 100.0 x 148.0 mm to max. 216.0 x 356.0 mm)

Multi-Purpose Tray

A4, A5, A6, Legal, Letter, Foolscap, Indian Legal, Index Card, Envelope ( COM10, Monarch, DL, C5), Custom (min. 76.0 x 127.0 mm to max. 216.0 x 356.0 mm)

2-Sided Printing

A4, A5, Legal, Letter, Foolscap, Indian Legal,
Custom (min. 148.0 x 148.0 mm to max. 216 x 356.0 mm)

Media Type

Plain Paper, Recycled Paper, Colour Paper, Bond Paper

Media Weight

Cassette / Paper Feeder

60 – 200 g/m²

Multi-Purpose Tray

60 – 200 g/m²

Standard Interface

Wired

USB 2.0, 10Base-T/100Base-TX/1000Base-T

Wireless

Wi-Fi 802.11b/g/n
(Infrastructure Mode, Access Point, WPS)

Network Protocol

Print

LPD, RAW, IPP, IPPS, WSD-Print (IPv4, IPv6)

TCP/IP Application Services

mDNS, DHCP, Auto IP (IPv4), DHCPv6 (IPv6)

Management

SNMPv3 (IPv4, IPv6), HTTP/HTTPS, SNTP

Network Security

Wired

IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3

Wireless

Infrastructure Mode: WPA-PSK(AES), WPA2-PSK(AES), WPA3-SAE(AES), WPA-EAP(AES), WPA2-EAP(AES), WPA3-EAP(AES)
Access Point Mode: WPA2-PSK(AES), WPA3-SAE(AES)

Mobile Solution

Canon PRINT app, AirPrint®, Mopria® Print Service, Microsoft® Universal Print

Compatible Operating System^*3

Windows®, Windows Server®, macOS®, Linux, Chrome OS™

Other Features

Department ID, Secure Print, Application Library

Available Software

Printer Driver, Toner Status

Device Memory

1 GB

Storage (eMMC)

2 GB

Display

5" LCD Touchscreen

Power Requirements

AC 220 – 240 V, 50/60 Hz

Power Consumption (Approx.)

Operation

700 W (max. 1380 W)

Standby

24 W

Sleep

1 W

Operating Environment

Temperature

10 – 30°C

Humidity

20 – 80% RH (no condensation)

Monthly Duty Cycle^*4

50,000 pages

Dimensions (W x D x H)

425 x 427 x 380 mm

Weight^*5 (Approx.)

16.1 kg

Toner Cartridge^*6

Standard

Cartridge 069 BK: 2,100 pages (Bundled: 1,200 pages)
Cartridge 069 CMY: 1,900 pages (Bundled: 1,100 pages)

High

Cartridge 069H BK: 7,600 pages
Cartridge 069H CMY: 5,500 pages
