Epson ColorWorks C8050 (Gloss Black) Color Label Printer(C31Cl02106E1)



Connectivity:

---

USB:USB 3.0 (one port), USB 2.0 (one port)

Wi-Fi:Optional Wi-Fi dongle available (OT-WL06)

Ethernet:100Base-T/100Base-TX/10Base-T

General-Purpose I/O Port:D-Sub 25

Print Utilities and Remote Management Tools:EpsonNet SetupManager, EpsonNet Config SE, Epson Device Admin,
Epson Deployment Tool, PrinterSetting, Colour Tone Matching Assistant,
USB Printer Class Device Replacement, Epson Firmware Updater,
Epson Cloud Solution PORT^*3 Production Monitor, WebConfig

Direct Command-Based Printing:Zebra^® ZPL II® native language support, plus command extensions, to allow for colourisation of data; ESC/Label color command language; SAP^® Direct Printing

Ink:

---

Ink Type:UltraChrome DL SJIC52P Pigment Ink

Colours:Black (Gloss or Matte Black Options), Cyan, Magenta, Yellow

Ink Pack Configuration:Four (4) individual ink packs

Ink Pack Capacity:480 ml each pack^*2

Acoustic Noise:

---

Acoustic Noise:Approx. 57 db

EMI:FCC Class A, ICES-003 Class A

Display:

---

Display:2.7” Colour LCD

Environmental Conditions:

---

Temperature:Operating: 5°C to 35°C / Storage: -15°C to 40°C,
Up to 120 H; Matte Black Ink: -10°C to 40°C

Humidity:Operating: 20% – 80% RH (No Condensation)

Electrical Specifications:

---

Rated Voltage:100 V – 240 V

Rated Frequency:50 Hz – 60 Hz

Power Consumption:Operating: Approx. 83.0 kW; Standby: Approx. 3.3 W; Power Off: Approx. 0.4 W

Print:

---

Printhead:PrecisionCore Printhead, permanent

Printing Technology:PrecisionCore Line Inkjet Technology

Maximum Print Resolution:600 x 1,200 dpi

Maximum Print Speed^*1:Up to 300 mm per second (11.8”/sec)

Colour Adjustment:Epson Preferred Colour, Epson Standard, Epson Vivid Colour

Media Dispense Type:Auto Cutter (scissor type), up to 1.5 million cuts

Paper-Feeding Mechanism Life:500 km

Media:

---

Supported Media Types:Die-Cut Label, Full-Page Label, Continuous Label, Tag

Supported Media Constructions:Plain Paper, Textured Paper, Matte Paper, Synthetic,
Glossy Paper, Glossy Film, High Glossy Paper

Die-cut Label Gap:3 mm – 6 mm (0.12” – 0.24”)

Gap Sensor Position:Adjustable; 3 mm – 56 mm (0.12” – 2.20”)
from left side; pitch: 1 mm (0.04”)

Maximum Print Width:108 mm (4.25”)

Black Mark Sensor Position:Fixed position; approximately 12.4 mm (0.49”) from left

Black Mark Wdith:19 mm (0.75”) or more from paper edge

Black Mark Length:4 mm – 25.4 mm (0.16” to 1.0”) with 4 mm (0.16”) or more
of white space around the black mark

Media Width (Min. – Max.):Internal Roll Media : 25.4 mm – 112 mm (1.0” – 4.40”)
External Roll Media, Fanfold : 50 mm – 112 mm (1.97” – 4.40”)

Media Length (Min. – Max.):8 mm – 1,016 mm (0.31” – 40”)

Media Thickness (Min. – Max.):0.084 mm – 0.600 mm (3.30 mils – 23.62 mils)

Internal Roll Media:Media Core Inner Diameter: 76.2 mm (3.0”)
Media Maximum Outer Diameter: 203.2 mm (8.0”)

Supported Operating System:

---

Supported Operating System:Windows^® 11, Windows 10 (32-bit/64-bit, Windows 8.1 (32-bit/64-bit),
Windows Server^® 2022, Windows Server 2019, Windows Server 2016,
Windows Server 201, Windows Server 2012 R2, OS X^® 10.9.5 or later
MacOS^® 10.12 or later, CentOS^® 7 (x86_64), Ubuntu 20.04 (x86_64)

Printer Dimensions (W x D x H):

---

Printer Dimensions (W x D x H):620 x 392 x 420 mm / 24.4 x 15.4 x 16.5 inch

Printer Weight:

---

Printer Weight:Approx. 35 kg

Packaging Dimensions (W x D x H):

---

Packaging Dimensions (W x D x H):818 x 576 x 616 mm / 32.2 x 22.7 x 24.3 inch

Packaging Weight:

---

Packaging Weight:Approx. 43 kg

Eco Features:

---

Eco Features:RoHS compliant, Actively uses recycled plastic parts
Reduces waste materials by using Replaceable Ink Pack System (RIPS)
