Print

Fast: 71.4 m²/hr on plain media; Normal: 17.2 m²/hr on coated media; Best: 4.5 m²/hr on glossy media ¹

7/3 pl dual-drop weight (M, C, PK, CB, G); 6 pl single-drop weight (Y, CR, MK, CG)

2112 per colour; 21,120 in total

HP 746 Ink Cartridge: cyan, magenta, chromatic red, yellow, matte black, photo black (300 ml); HP 747 Ink Cartridge: chromatic green, chromatic blue, grey (300 ml)

Pigment-based

9 (cyan, magenta, yellow, matte black, photo black, chromatic red, chromatic green, chromatic blue, grey), optional gloss enhancer

5 universal printheads (valid for all colours)

Cyan, magenta, yellow, matte black, photo black, chromatic red, chromatic green, chromatic blue, grey

Up to 2400 x 1200 optimised dpi

4 L* min/2.5 D ²

Roll feed, rear sheet feed, media output bin, automatic horizontal cutter

210 to 1118 mm wide sheets; 279 to 1118 mm rolls

135 mm

1

13.5 kg

HP Universal Instant-dry Satin Photo Paper (FSC® certified) ³ (Recyclable) ⁴; HP Artist Matte Canvas; HP Heavyweight Coated Paper (FSC® certified) ³ (Recyclable) ⁴; HP Everyday Matte Polypropylene (Recyclable) ⁴; HP Premium Matte Photo Paper (FSC® certified) ³ (Recyclable) ⁴

Up to 31.5 mil

Up to 0.8 mm

1118 mm

Digital fine art; Exhibition and event graphics; Graphics design; Photos; Point of sale/display; Posters

5 x 17 x 5 x 5 mm

5 x 5 x 5 x 5 mm (borderless on selected media ⁵)

210 x 279 to 1118 x 1676 mm

A4, A3, A2, A1, A0

Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit

80 to 500 g/m²

1118 mm

500 GB self-encrypting

±0.1% ⁶

Raster and PostScript drivers for Windows and macOS; PDF driver for Windows 8 and above

Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL

HP Thermal Inkjet

0.02 mm (PDF addressable @ 1200 dpi)

0.08 mm (ISO/IEC 13660:2001(E)) ⁷

Median < 1.6 dE2000, 95% of colors < 2.8 dE2000 ⁸

< 1 dE2000 in less than 5 minutes ²

Average < 0.5 dE2000, 95% of colours < 1.4 dE2000 ²

Apple AirPrint, direct printing from USB flash drive, email printing, HP Click, HP driver for macOS, HP driver for Windows, HP driver for Linux, printing support for Chrome OS, HP Print Service Plugin for Android, HP Smart app for iOS and Android, HP SmartStream

Gigabit Ethernet (1000Base-T) (802.3, 802.3u, 802.3ab); Hi-Speed USB 2.0 certified interface for direct printing from USB flash drive

Standard

HP Secure Boot, Whitelisting, Role Based Access Control, SNMPv3, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, Secure Disk erase (DoD 5220.22-M), Secure File erase, self-encrypted HDD, PIN printing

Direct print from mobile apps on iOS, Android and Chrome OS; email printing with HP ePrint and HP Smart app for iOS and Android.

1802 x 695 x 998 mm

1950 x 766 x 718 mm

94 kg

130 kg

128 GB (virtual) ⁹

6.0 B(A) (operating), 5.1 B(A) (idle), <3.4 B(A) (sleep)

42 dB(A) (operating), 33 dB(A) (idle), <16 dB(A) (sleep)

20 to 80% RH

5 to 40ºC

41 to 104ºF

-25 to 55ºC

-13 to 131ºF

<100 W (printing); <32 W (ready); <6.5 W (sleep); 0.1 W (off)

Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max

HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional), HP SmartTracker (optional)

Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS)

Yes

ENERGY STAR; ErP; WEEE; RoHS (EU, China, Korea, India); REACH; EPEAT

USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS)

One-year limited hardware warranty

HP DesignJet Z9+ PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord
