Huawei IdeaHub S2 Series 65″ 75″ 86″ Interactive display

Highlights

•

  BYOM

  Bring Your Own Meeting (BYOM) with seamless transfer from personal devices to HUAWEI IdeaHub S2.

•

  Wi-Fi 6 for Direct Projection

  One-step projection using Wi-Fi Direct without the need for devices to share the same local area network (LAN).

•

  Collaboration Unbounded

  Multi-Window and App Multiplier deliver an enriched office ecosystem.

•

  Professional-Level 4K Video Camera

  2 μm² ultra-large photosite size doubles the signal-to-noise ratio (SNR). Huawei-developed AI algorithm ensures true-to-life, natural clarity.

•

  AI-powered Audio and Video

  Voice tracking, Auto-Framing, and acoustic baffle deliver immersive experience. 12-meter sound pickup, DNN-based de-reverberation, and AEC algorithm ensure clear voice from far away.

•

  Intelligent Whiteboard

  Annotate on full screen in full color with an all-new toolbar. Writing is effortlessly smooth with intelligent recognition and ultra-low latency.



  Product Specifications

• The dimensions and weight may vary with configuration, manufacturing process, and measurement method. The product height includes the camera (55 mm).

  Product Name

  HUAWEI IdeaHub S2

  Product model

  65": IHS2-65SA
  75": IHS2-75SA
  86": IHS2-86SA

  Product dimensions
  (H x W x D)

  65": 947.5 mm x 1484.5 mm x 91.6 mm
  75": 1071.9 mm x 1705.7 mm x 91.8 mm
  86": 1212.0 mm x 1953.0 mm x 91.8 mm

  Net weight

  65": 35.5 kg
  75": 47.0 kg
  86": 62.0 kg

  Gross weight
  (including the package)

  65": 43.0 kg
  75": 57.0 kg
  86": 73.5 kg

  Component

  Device

  1

  Stylus pens

  2

  Cable

  Power cable x 1

  Wall-mounted bracket

  Optional (65", 75", and 86")

  Rolling stand

  Optional (65", 75", and 86")

  IdeaShare Key

  Optional (Type-A port)

  OPS

  Optional

  Screen

  Resolution

  4K (3840 x 2160 pixels)

  Backlight type

  D-LED

  Screen Lamination

  Zero-gap bonding

  Writing

  Latency

  16 ms

  Touch sensing distance

  ≤ 1.5 mm

  Intelligent writing recognition

  Supports recognition of Chinese, English, and 11 types of graphics

  Camera

  Resolution

  4K

  Sharpness

  1800 lines

  Lens cap for privacy protection

  √

  Horizontal FoV

  80°

  TV distortion

  ＜2%

  Speaker

  Frequency domain

  100 Hz to 20 kHz

  Number of speaker units

  4

  Total power

  40 W

  Microphone

  Sound pickup angle

  180°

  Sound pickup distance

  12 m

  Frequency domain

  80 Hz to 20 kHz

  Optimized sound pickup

  Sound location, echo cancellation, and automatic gain control

  Meeting

  Native meeting apps

  Huawei Cloud Meeting and WeLink

  Dual streams (audio/video + data sharing)

  1080p30fps+1080p30fps/4K8fps

  BYOM

  √

  AI Function

  Auto-Framing

  √

  Intelligent tracking

  √

  Acoustic baffle

  √

  DNN-based dereverberation

  √

  System

  RAM

  8 GB

  Flash

  64 GB

  OS

  HarmonyOS, Windows (OPS required)

  Security

  Embedded encryption chip that supports H.235, STARTTLS, TLS, SRTP encryption, Chinese cryptographic algorithms, secure boot, and TEE

  Language

  Simplified Chinese, English, French, Japanese, Arabic, Spanish, Russian, Portuguese, and Italian

  Wireless connection

  Wi-Fi module

  Wi-Fi 6

  Wi-Fi frequency

  2.4 GHz + 5 GHz

  NFC

  √

  Port

  Video input

  HDMI cable x 1

  Video output

  HDMI cable x 1

  Audio input

  3.5 mm (line-in) x 1
  HD-AI x 1

  Audio output

  3.5 mm (line-out) x 1

  Other ports

  USB Type-A 3.0 x 3
  USB Type-C x 1
  RJ45 (10/100/1000 Mbit/s LAN) x 1
