Performance
Up to 7,250MB/s of sequential read speed, 45% faster speed than the previous model.
Power efficiency
Power efficiency enhanced by 73% for more MB/s per watt, while maintaining performance and thermal control.
Versatility
Up to 4TB expanded capacity and rapid Intelligent
TurboWrite 2.0 with enlarged TurboWrite region.
Specifications
Application
Client PCs
Rated Capacity
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0
Dimension (Pack: WxHxD)
Max 80.15 x Max 22.15 x Max 2.38 mm
Weight
Max 9.0g Weight
Storage Memory
Samsung V-NAND TLC
Controller
Samsung in-house Controller
Cache Memory
HMB(Host Memory Buffer)
Special Feature
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 7,150MB/s*
Sequential Write
Up to 6,300MB/s*
Random Read (4KB, QD32)
Up to 850,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)
Up to 1,350,000 IOPS * Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
Average: Read 4.3 W / Write 4.2 W* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)
Typical 60 mW * Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Device Sleep)
Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 – 70 ℃ Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
Warranty
5-year Limited Warranty or 600TBW Limited Warranty
Weight
0.20 kg
Dimensions
10.00 × 10.00 × 5.00 cm
Option
EVO PLUS 1TB, EVO PLUS 2TB, EVO PLUS 4TB
